The Gill Corporation’s most economical aluminum honeycomb, Commercial Grade Honeycomb is a lightweight structural core material that offers excellent strength and corrosion resistance to meet a wide variety of applications.
在加工成蜂窝之前，对铝箔应用先进的保护系统，延长其在热、湿和腐蚀性环境中的使用寿命。吉尔公司生产三种等级的商业级蜂窝： 商业级蜂窝，我们的标准等级。商业级蜂窝铝蜂窝是一种高性能、低成本的芯材，非常适合建筑、交通、船舶和其他商业/工业应用。
商业级蜂窝铝蜂窝可提供蜂窝孔以促进通风。
可提供定制尺寸、单元尺寸、公差和机械性能
订购时，请使用以下格式指定商业级蜂窝：
Example: Commercial Grade Honeycomb – 3.5 – 1/4 – N – E, where
| 产品 | 密度 | 像元大小 | 穿孔或非穿孔 | 扩展或未扩展 |
|---|---|---|---|---|
| 商业级蜂窝 | 3.5 | 1/4 | A片 | E或U |
基质： 3000系列铝材
涂层： 无（阳极氧化）
| 标准 | 最大限度 | 宽容 | |
|---|---|---|---|
| 色带 (L) 英寸 (mm) | 48 (1,219) | 100 (2,540) | +4.0 / -0.0 (+101.6 / -0.0) |
| 横向 (W) 英寸 (mm) | 96 (2,438) | 300 (7,620) | +8.0 / -0.0 (+203.2 / -0.0) |
| 厚度 (T) 英寸 (mm) | 35 (889) | ||
| 高达 4 英寸（102 毫米）T | ±0.008 (±0.203) | ||
| 超过 4 英寸（102 毫米）T | ±0.062 (±1.575) | ||
| 密度 | 见机械特性表 | ±15% | |
| 像元大小 | 见机械特性表 | ±15% | |
(Commercial Grade Aluminum Honeycomb Typical values at 75° F / 23° C)
| 密度单元尺寸 | 裸抗压强度 | 压碎强度 | 剪切强度 | 剪切模量 | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 大号 | W | 大号 | W | |||||||||
| 磅/英尺3 – inches | 压力 | 兆帕 | 压力 | 兆帕 | 压力 | 兆帕 | 压力 | 兆帕 | ksi | 兆帕 | ksi | 兆帕 |
| 5.2 – 1/4 | 640 | 4.41 | 250 | 1.73 | 380 | 2.62 | 220 | 1.52 | 70 | 483 | 40 | 276 |
| 3.6 – 3/8 | 350 | 2.41 | 130 | 0.90 | 240 | 1.65 | 140 | 0.97 | 46 | 317 | 23 | 159 |
| 2.6 – 1/2 | 195 | 1.34 | 75 | 0.52 | 150 | 1.03 | 85 | 0.59 | 28 | 193 | 15 | 104 |
| 1.8 – 3/4 | 125 | 0.86 | 50 | 0.34 | 110 | 0.76 | 70 | 0.48 | 20 | 138 | 10 | 69 |
| 1.3 – 1.0 | 85 | 0.59 | 30 | 0.21 | 70 | 0.48 | 50 | 0.34 | 14 | 97 | 7 | 48 |
当遵循推荐的预防措施时，本产品可以安全使用和应用。使用本产品前，请阅读并理解 安全数据表 (SDS)，其中提供有关健康、身体和环境危害、处理预防措施和急救建议的信息。仅供工业使用。离孩子远点。其他信息可在以下位置找到： www.thegillcorp.com.如需销售和订购信息，请致电 1-626-443-6094。
All recommendations, statements, values and technical data herein are based on tests The Gill Corporation believes to be reliable and correct, but accuracy and completeness of said tests are not guaranteed and are not to be construed as a warranty, either expressed or implied. Users shall rely on their own information and tests to determine suitability of the product for the intended use and assume all risks and liability resulting from their use of the product. The Gill Corporation’s sole responsibility shall be to replace that portion of the product that proves to be defective. The Gill Corporation will not be liable to the buyer or any third person for any injury, loss or damage directly or indirectly resulting from use of, or inability to use, the product. Recommendations or statements not contained in a written agreement signed by an officer of The Gill Corporation shall not be binding upon The Gill Corporation. Alcopan™, Alphex®, CGH® Dura-Core®, Gillfab®, Gillfloor®, Gilliner®, Gillite®, Gillfists®, GillVANA®, Higrid®, Hushgrid®, PAA-Core®, Plygrid®, Shapegrid®, Strikegrid®, Trussgrid® are registered trademarks of The Gill Corporation.
